一、概述
我公司的超寬頻帶功率放?器模塊具有?效率、?可靠性,是使?GaN器件的全固態放?器模塊。主要?于測試和測量?jī)x器、通信或?擾、航空管制等領域。該產品具?增益調節，溫度檢測與告警保護，功率檢測與告警保護，?扇檢測與告警保護，電流檢測與告警保護等功能；同時還具有LCD電?顯示屏顯?溫度、電流、故障等。
二、特點
- PIND 功率指?（內置耦合器）
- USUP AC或DC
- GADJ 20dB調整范圍
- LAN 可通過LAN進?遠程監控
- Rs232 可通過RS232進?遠程監控
- Rs485 可通過RS485進?遠程監控
三、可選型號
|
產品型號 |
頻率 |
最小輸出功率 |
小信號增益 |
二次諧波(dBc) |
增益平坦度 |
|
ESM 30Sz01G1 |
0.01-1 |
30 |
49 |
-15 |
±2 |
|
ESM 1Sz1G12 |
0.1-12 |
0.6 |
32 |
-15 |
±1 |
|
ESM 50Sz42Gz52 |
0.42-0.52 |
50 |
53 |
-15 |
±1 |
|
ESM 20Sz05G6 |
0.05-6 |
20 |
46 |
-15 |
±3 |
|
ESM 20Sz7G2z7 |
0.7-2.7 |
20 |
45 |
-15 |
±1.5 |
|
ESM 20Sz7G4z2 |
0.7-4.2 |
20 |
47 |
-15 |
±3 |
|
ESM 16Sz7G6 |
0.7-6 |
16 |
47 |
-15 |
±3.5 |
|
ESM 50Sz7G6 |
0.7-6 |
50 |
53 |
-15 |
±4 |
|
ESM 80S1z8G2z2 |
1.8-2.2 |
80 |
53 |
-15 |
±3 |
|
ESM 20S2G6 |
2-6 |
20 |
47 |
-15 |
±2 |
|
ESM 50S2G8 |
2-8 |
50 |
50 |
-15 |
±3 |
|
ESM 10S2G18 |
2-18 |
10 |
44 |
-15 |
±4 |
|
ESM 16S2G18 |
2-18 |
16 |
46 |
-15 |
±4 |
|
ESM 20S2G18 |
2-18 |
20 |
46 |
-15 |
±4 |
|
ESM 30S2G18 |
2-18 |
30 |
48 |
-15 |
±4 |
|
ESM 40S2G18 |
2-18 |
40 |
49 |
-15 |
±4 |
|
ESM 5S6G18 |
6-18 |
5 |
40 |
-15 |
±3 |
|
ESM 10S6G18 |
6-18 |
10 |
43 |
-15 |
±3 |
|
ESM 20S6G18 |
6-18 |
20 |
49 |
-15 |
±3 |
|
ESM 50S6G18 |
6-18 |
50 |
54 |
-15 |
±3 |
|
ESM 100S6G18 |
6-18 |
100 |
55 |
-15 |
±3.5 |
|
ESM 30S8G12 |
8-12 |
30 |
50 |
-35 |
±3 |
|
ESM 50S8G12 |
8-12 |
50 |
51 |
-35 |
±3 |
|
ESM 5S8G15 |
8-15 |
5 |
41 |
-35 |
±3 |
|
ESM 50S9G11 |
9-11 |
50 |
51 |
-30 |
±2.5 |
|
ESM 1S18G26z5 |
18-26.5 |
1 |
32 |
-15 |
±2 |
|
ESM 5S18G26z5 |
18-26.5 |
5 |
38 |
-15 |
±3 |
|
ESM 10S18G26z5 |
18-26.5 |
10 |
45 |
-15 |
±3 |
|
ESM 20S18G26z5 |
18-26.5 |
20 |
46 |
-15 |
±3 |
|
ESM 40S18G26z5 |
18-26.5 |
40 |
49 |
-15 |
±3 |
|
ESM 50S18G26z5 |
18-26.5 |
50 |
50 |
-15 |
±4 |
|
ESM 15S26z5G35 |
26.5-35 |
15 |
46 |
-15 |
±5 |
|
ESM 20S26z5G35 |
26.5-35 |
20 |
48 |
-15 |
±5 |
|
ESM 4S26z5G40 |
26.5-40 |
4 |
38 |
-15 |
±4 |
|
ESM 5S26z5G40 |
26.5-40 |
5 |
40 |
-15 |
±4 |
|
ESM 10S26z5G40 |
26.5-40 |
10 |
45 |
-15 |
±4 |
|
ESM 15S26z5G40 |
26.5-40 |
15 |
45 |
-15 |
±4 |
|
ESM 20S26z5G40 |
26.5-40 |
20 |
48 |
-15 |
±4 |
|
ESM 40S26z5G40 |
26.5-40 |
40 |
50 |
-15 |
±4 |
|
ESM 1Sz01G50 |
0.01-50 |
1 |
27 |
-20 |
±5 |
|
ESM 1S2G50 |
2-50 |
1 |
27 |
-20 |
±5 |
|
ESM 01S40G57 |
40-57 |
0.1 |
24 |
-15 |
±2 |
|
ESM 1S44G50 |
44-50 |
1 |
35 |
-15 |
±2 |
|
ESM 2S47G57 |
47-57 |
2 |
37 |
-15 |
±2 |
|
ESM 1S57G36 |
57-36 |
1 |
35 |
-15 |
±2 |
|
ESM 1S89G96 |
89-96 |
1 |
35 |
-15 |
±2 |
|
ESM 1S75G110 |
75-110 |
1 |
35 |
-15 |
±4 |
|
ESM 1S88G100 |
88-100 |
1 |
35 |
-15 |
±3 |
|
ESM 1S90G110 |
90-110 |
1 |
35 |
-15 |
±3 |
|
|
|
|
|
|
|
